Parts

AVAILABLE ACCESSORIES

  • P0 purification cartridge
  • Certified air test with documentation
  • Gasket kit
  • Valve overhaul kit
  • Inlet filter element
  • Fill gauge ( Fill gauge with calibration option)
  • 5 ft. fill hose
  • Gasket, O-ring, and seals kit

STANDARD SCOPE OF SUPPLY

OCEANUS-E3Y-NOAA

  • Heavy-duty stainless steel base and stainless steel inner frame
  • Compressor base plate with stainless steel fittings
  • Magnetic starter and power-on light
  • High temperature and final pressure switch
  • Hourmeter and on/off switch
  • Automatic condensate drain system
  • Safety relief valves for each stage of compression
  • Inlet filter and oil dipstick
  • Vibration isolators and belt guard
  • NEMA 4x electric enclosure
  • P0 purification system
  •  UV-resistant molded plastic flywheel cover

HC5000-2

  •  Two (2) each 5000 PSIG UN code stamped cylinders mounted in a vertical rack
  •  Price includes cylinder-integrated piping

CFS5.5-2S

  • 2 Position SCBA containment fill station

SYSTEM FOOTPRINT

OCEANUS-E3Y/NOAA:

DIMENSIONS L X W X H inches (mm)

  • 32” x 18” x 23” (813mm x 457mm x 584mm)

WEIGHT pounds (kg)

  • 135 lb (61 kg)

HC5000-2:

DIMENSIONS L X W X H inches (mm)

  • 17.5” x 26” x 65” (445mm x 660mm x 1651mm)

WEIGHT pounds (kg)

  • 450 lb (204 kg)

CFS5.5-2S:

DIMENSIONS L X W X H inches (mm)

  • 30” x 21” x 53” (762mm x 533mm x 1346mm)

WEIGHT pounds (kg)

  • 670 lb (304 kg)
Model Charging Rate1 Number of Stages Motor FAD2 RPM Purification Sytems
  SCFM L/MIN   HP kW


OCEANUS-E3Y/NOAA

4.9

139

 3 5 3.7 4.1 2150 P0

1) Based on recharging an 80 cubic foot tank from 500 to 3000 psig.  2) Compressor capacity referenced to standard inlet conditions.  Dimensions and weight are approximate and are subject to change.

A. BAUER COMPRESSOR warranty includes parts and labor 12 Months from the date of compressor start-up or 18 Months from the date of shipment.

B. Spare parts consisting of normal wear and tear items, e.g., replacement cartridges, valve overhaul kits, gasket kits, belts, oil, inlet filter element, etc., are normal stock items at BAUER NORFOLK, BAUER SAN FRANCISCO, and BAUER NORTHEAST.
