SYSTEM FOOTPRINT
Dimensions L x W x H inches (mm) approx.*
- 97” x 58” x 85” (2464 mm x 1473 mm x 2159 mm)
WEIGHT pounds (kg) approx.*
- 3200-4000 lbs (1066-1814 kg)
*Depending upon model and options
Technical Data
| Model | Max Inlet Pressure | Capacity FGD1 | RPM | Number of Stages | Motor | Drive | |||
| PSIG | mBAR | SCFM | M3/HR | HP | kW | ||||
| UP TO 3190 PSIG OPERATING PRESSURE | |||||||||
| GAR23.2 | atm | atm | 26 | 44 | 1140 | 4 | 30 | 22 | E3 |
| GAR23.2 | atm | atm | 32 | 55 | 1420 | 4 | 40 | 30 | E3 |
| UP TO 4350 PSIG OPERATING PRESSURE2 | |||||||||
| GAR23.2 | 8.7-14.5 | 0.6-1 | 42-53 | 72-90 | 1140 | 4 | 50 | 37 | E3 |
| GAR23.2 | 8.7-14.5 | 0.6-1 | 51-64 | 87-109 | 1420 | 4 | 60 | 45 | E3 |
1 Volume flow rate according to ISO 1217. Valid for Helium. Contact BAUER for performance verification for Argon. Actual performance values may vary depending upon site conditions.
2 These models must have the mentioned inlet pressure.
