SYSTEM FOOTPRINT
Dimensions L x W x H inches (mm) approx.*
- 97” x 58” x 85” (2464 mm x 1473 mm x 2159 mm)
Weight pounds (kg) approx.
- 97” x 58” x 85” (2464 mm x 1473 mm x 2159 mm)
Depending upon the model and options
*Dimensions exclude vent stack
Technical Data
| Model | Max Inlet Pressure | Capacity FGD1 | RPM | Number of Stages | Motor | Drive | |||
| PSIG | mBAR | SCFM | M3/HR | HP | KW | ||||
| UP TO 3190 PSIG OPERATING PRESSURE | |||||||||
| GHE25.9 | <1 | 50 | 54 | 91 | 1180 | 5 | 60 | 45 | E3 |
| UP TO 4900 PSIG OPERATING PRESSURE | |||||||||
| GHE25.9 | <1 | 50 | 47 | 79 | 1050 | 5 | 60 | 45 | E3 |
| GHE25.18 | <1 | 50 | 64 | 108 | 1100 | 5 | 75 | 55 | E3 |
1 Volume flow rate according to ISO 1217. Valid for Helium. Contact BAUER for performance verification. Capacities referenced to atmospheric inlet pressure. Motor power valid for max. inlet and final pressure. Actual performance values may vary depending on site conditions.
