SYSTEM FOOTPRINT
Dimensions L x W x H inches (mm)
- 216-297.6" L x 87.6-99.6” W x 117” H (5486.4-7543.8 mm x 2225.04-2529.84 mm x 2971.8 mm)
WEIGHT pounds (kg)
- 18000-22700 lbs (8165-10297 kg) Approximately
Technical Data
| Model | Max Inlet Pressure2 | Capacity FGD1 | RPM | Number of Stages | Motor | Drive | |||
| PSIG | BAR | SCFM | M3/HR | HP | kW | ||||
| UP TO 5000 PSIG OPERATING PRESSURE(ELEVATED INLET PRESSURE)2 | |||||||||
| GBHE26.10 | 29-65 | 2-4.5 | 147-271 | 250-461 | 1485 | 4 | 177-215 | 132-160 | E3 |
| GBHE26.12 | 65-145 | 4.5-10 | 152-305 | 259-518 | 1485 | 4 | 177-215 | 132-160 | E3 |
| GBHE26.13 | 145-217 | 10-15 | 220-322 | 374-547 | 1485 | 4 | 335-422 | 250-315 | E3 |
| GBHE52.10 | 29-65 | 2-4.5 | 297-543 | 504-922 | 1485 | 4 | 335-422 | 250-315 | E3 |
| GBHE52.12 | 65-145 | 4.5-10 | 305-613 | 518-1042 | 1485 | 4 | 335-422 | 250-315 | E3 |
| GBHE52.13 | 145-217 | 10-15 | 441-644 | 749-1049 | 1485 | 4 | 335-442 | 250-315 | E3 |
1 Volume flow rate according to ISO 1217. Valid for Helium. Contact BAUER for performance verification. Capacities referenced to atmospheric inlet pressure. Motor power valid for max. inlet and final pressure. Actual performance values may vary depending upon site conditions. 2 Lower inlet pressure can result in lower operating pressure. Contact BAUER for min. / max. operating pressure relative to inlet pressure
