SYSTEM FOOTPRINT

DIMENSIONS L X W X H inches (mm)

  • 480" x 96" x 96"
    (12,192mm x 2438mm x 2438mm)

AVAILABLE OPTIONS

  • Marine/offshore special paint
  • Class I, Div II for hazardous zone classification
  • Two-stage intake filter for high-dust environments
  • CE compliance
  • BAUER CONNECT® IoT Remote Telemetry

TECHNICAL DATA

Model Motor Size Nitrogen Purity Nitrogen Flow Discharge Pressure
  HP kW   SCFM M3/HR PSIG BAR
BAUER NGM® 42
NGM 42-350 350 260 96% 354 601 150 10
NGM 42-350 350 260 97% .323 549 150 10
NGM 42-350 350 260 98% 312 530 150 10
NGM 42-350 350 260 99% 243 413 150 10
NGM 42-350 350 260 99.5% 188 319 150 10
BAUER NGM® 76
NGM 76-500 500 373 96% 453 770 150 10
NGM 76-500 500 373 97% 370 629 150 10
NGM 76-500 500 373 98% 359 610 150 10
NGM 76-500 500 373 99% 283 481 150 10
NGM 76-500 500 373 99.5% 226 384 150 10
BAUER NGM® TS
NGM TS-750 750 560 96% 614 1043 300 20
NGM TS-750 750 560 97% 558 948 300 20
NGM TS-750 750 560 98% 500 850 300 20
NGM TS-750 750 560 99% 350 595 300 20
NGM TS-750 750 560 99.9% 315 535 300 20

Note: NGM performance data is stated at the following ambient conditions: Temperature:  110⁰ F/43⁰ C, Elevation: sea level, Relative Humidity: 65%
